B13960S Battery Exploded View
B13960S Battery Exploded View
| No. 序号 | Part number 物料编码 | Part name 物料名称 | |
| 1 | 02-001-02795 | B13860S,B13960S Battery Corner Rubber Pad (Bottom) B13860S,B13960S 电池塑料壳脚垫 （A0） | |
| 2 | 02-001-06891 | B13860S,B13960S Battery Handle Bracket B13860S,B13960S 电池把手盖 | |
| 3 | 02-001-03656 | B13860S,B13960S Battery Handle B13860S,B13960S 伸缩把手_TPE版（A0） | |
| 4 | 02-002-07478 | B13960S Battery Top Casing B13960S V5电池头壳 | |
| 5 | 14-004-00072 | B13960S Battery Motherboard B13960S V5电池主板 | |
| 6 | 02-002-07223 | B13960S Negative Power Outlet Cord B13960S 电源负极铜排（短） | |
| 7 | 02-001-06622 | B13960S Battery Middle Deck B13960S V5电池隔板 | |
| 8 | 02-001-06621 | B13960S Battery Bottom Casing B13960S V5电池下壳 | |
| 9 | 02-001-02795 | B13860S,B13960S Battery Corner Rubber Pad (Bottom) B13860S,B13960S 电池塑料壳脚垫 （A0） | |
| 10 | 14-004-00028 | B13960S Battery Clip Kit B13960S 卡口组件 | |
| 11 | 14-004-00027 | B13960S Battery Outlet Socket Housing B13960S V5电池插头固定壳带胶垫 | |
| 12 | 01-027-01895 | B13960S Battery Outlet Socket B13960S 2021款电池插头 |
