Agricultural Drone Instruction Manual
Warranty Coverage Scope: Examples
Version 1.0
Circumstances Voiding Warranty Coverage
The following circumstances void all warranty coverage, requiring paid repair services:
1. Damage caused by natural disasters including earthquakes, floods, wildfires, etc.
2. Damage resulting from failure to follow User Manual procedures for operation, repair, or maintenance.
3. Damage from human factors, aftermarket modifications, or addition/removal of accessories.
4. Exterior paint/chrome damage, rust on external components, or use of non-genuine parts.
5. Absence of valid purchase invoice, mismatch between airframe serial number and invoice, or altered invoices.
6. Service promises by Party B (agents) exceeding the authorized distributor agreement.
7. Deleted or damaged flight logs preventing valid warranty assessment.
8. Reports of shipping damage or missing parts filed >7 days post-delivery (exceptions require quality incident reports).
9. Damage/missing parts claims after transfer to secondary distributors or end-users.
10. Other exclusions mandated by applicable laws and regulations.
No. | Module | Component | Exclusions (Visual Identification Criteria) |
1 | Drone | Complete unit | ①Operation violating User Manual (overload flight, exceeding safe altitude/speed, forced motor unlocking) ② Usage in no-fly zones, severe weather (gales, storms, thunderstorms) or electromagnetic interference environments ③ Human-induced crashes, collisions, water immersion, or compression damage ④ Transportation-related damage ⑤ Corrosion from prolonged exposure to acidic/alkaline chemicals ⑥ Unprotected exposure to high temp (>40°C), humidity, or dust causing motor/bearing/PCB degradation ⑦ Improper battery storage (full/empty >3 months) ⑧ Damage from skipped maintenance ⑨ Natural disasters (floods, earthquakes, lightning) or fire damage ⑩ Animal damage (e.g., rodent cable chewing) |
2 | Power System | Propeller assembly | â‘ Obstacle impact (trees, wires, structures) causing breakage/deformation â‘¡ Compression/bending during transport/storage without protectors â‘¢ Chemical erosion from unwashed pesticides causing material embrittlement |
Power System | Motor/ESC | â‘ Crash/impact-induced housing fractures â‘¡ Foreign debris (grass/sand) causing bearing wear or coil short circuits â‘¢ Blocked heat dissipation vents causing overheating â‘£ Corrosion from unremoved pesticides |
3 | Spraying System | Centrifugal nozzle Water tubes Water pump Flow sensor | ①Clogging/corrosion from unwashed pesticide residue ② Flow disruption from uncleaned filters ③ Corrosion from acidic/alkaline pesticides on metal components ④ Short circuits from liquid ingress in connectors ⑤ Transportation/installation damage ⑥ Plastic deformation from extreme temperatures |
4 | Spreading System | / | â‘ Residue accumulation from uncleaned materials (urea, fertilizer) â‘¡ Obstacle impact damage (branches, wires) â‘¢ Transport collision damage |
5 | Joints/Landing Gear | Joint locks | Corrosion from unremoved acidic/alkaline chemicals |
|
| Inner joints | Breakage from improper operation (crashes/collisions) |
|
| Outer joints | â‘ Bending/breakage from overload flight â‘¡ Transport impact damage |
|
| Landing gear | â‘ Hard landings causing deformation/breakage â‘¡ Unsecured transport damage â‘¢ Unauthorized modifications â‘£ Loose fastener failure |
6 | Other Components | Airframe | Deformation from human-induced collisions |
|
| Camera | Physical damage from crashes/obstacle impacts |
|
| Avionics system | Water immersion/high-voltage contact damage |
|
| Wiring harness | Transport compression/stretching or chemical corrosion |
|
| Other | Human-damaged RTK antennas, data transmission antennas |
7 | Accessories | Fuel generator | ①Operator-caused fires ② Neglected maintenance (oil/filter replacement) ③ Transport impact damage ④ Engine seizure from oil starvation ⑤ Unauthorized modifications ⑥ Industrial overuse |
Charger | â‘ Physical damage (drops, casing cracks) â‘¡ High-temp/humidity/flammable environment use â‘¢ Unauthorized disassembly â‘£ Non-genuine cable/modification damage | ||
Remote controller | â‘ Liquid damage (rain, spills) â‘¡ Drop/transport impact damage | ||
Battery | ①Natural capacity decay from usage cycles ② Age-related resistance increase/runtime reduction ③ Physical damage (dents, swelling) ④ Overcharging/deep discharging ⑤ High-temp/humidity storage ⑥ Improper storage maintenance ⑦ >3-month storage at full/empty charge ⑧ Cosmetic wear |
